Planet 24-Port 10/100+ 4 Gigabit TP/2-Port mini-GBIC L3 Switch/WGS3-2820
[WGS3-2820]

Bs.25.622,70-Iva Incl.

Planet 24-Port 10/100+ 4 Gigabit TP/2-Port mini-GBIC L3 Switch/WGS3-2820 :: Detalle de Producto :: The PLANET WGS3-2820 is a 24-Port 10/100Mbps Layer 3 Managed Ethernet Switch. Its essentials Layer 3 functionality of multimedia switch brings high-end security and traffic control to the edge of the network. With IP routing capability and flexible management tools, the PLANET Managed Multi-Layer Switch Solution performs a cost-effective solution for today with the ability to expend as the growing of network demands.

Model	WGS3-2820
Hardware Specification
10/100Base-TX Ports	24 RJ-45 Auto-MDI / MDI-X ports
10/100/1000Base-T Ports	4 RJ-45 Auto-MDI / MDI-X ports
SFP / mini-GBIC Slots	2 SFP interfaces
Switch Architecture	Store-and-Forward
Switch Fabric	12.8Gbps Capacity
Switch Throughput	9.5Mpps
Address Table	16K MAC address table with Auto learning function
Layer 3 Routing Table	2048
Buffer Memory	2Mbits for packet buffer
Flow Control	Back pressure for Half-Duplex IEEE 802.3x Pause Frame for Full-Duplex
LED	Power, Link / Act– for per port status definition
Layer 2 / Layer 3 function
Management Interface	Console. Telnet, SSH, Web, SSL, SNMP
Port Configuration	Port disable / enable. Auto-negotiation 10/100Mbps full and half duplex mode selection. Flow Control disable / enable. Bandwidth control on each port.
Port Status	Display each port’s speed duplex mode, link status and Flow control status. Auto negotiation status and trunk status.
VLAN	IEEE 802.1Q Tagged Based VLAN ,up to 4041 VLAN groups
Port trunking	Supports 10 groups of 8-Port trunk
QoS	Traffic classification based on Port Number, 802.1p priority and DS / TOS field in IP Packet
IGMP Snooping	Allow to be disabled or enable.
IP Routing Protocol	Static Route, RIPv1 / v2, OSPFv2, IRDP, VRRP
Multicast Routing Protocol	DVMRP, PIM-DM / SM
Standards Conformance
Regulation Compliance	FCC Part 15 Class A, CE
Standards Compliance	IEEE 802.3　　 10BASE-T IEEE 802.3u　　100BASE-TX / 100BASE-FX IEEE 802.3z　　Gigabit SX/LX IEEE 802.3ab　 Gigabit 1000T IEEE 802.3x　　Flow Control IEEE 802.3ad　 Port trunk with LACP IEEE 802.1d　　Spanning tree protocol IEEE 802.1w　　Rapid Spanning tree protocol IEEE 802.1s　　Multiple Spanning Tree Protocol IEEE 802.1p　　Class of service IEEE 802.1Q　　VLAN Tagging
Physical Specifications
Dimensions (W x D x H)	430 x 44.5 x 350 mm, 1U height
Weight	4.5 KG

Para mas informacion visite la página del Producto Website del producto.

:: Si el producto tiene su precio en 0,00 (Cero) es posible que este agotado o aun no se haya cargado al sistema, tambien ese producto puede ser traido expresamente (Contra Pedido), consulte a nuestros operadores ::

::: POR FAVOR CONSULTE PRECIOS Y DISPONIBILIDAD ANTES DE REALIZAR SU COMPRA ::: Teléfonos : 0212 576 4667 / 0212 8808002 / 0416 6076958 / 0412 6076958 /

Atención en Línea: braincorp@hotmail.com , cesar.gamboa.braincorp@hotmail.com, fermar53@hotmail.com, mirianesther@hotmail.com, alberto.braincorp@hotmail.com braincorp2001@yahoo.com mirianesther@yahoo.com :::

Brochure del Producto
