Planet Gigabit IEEE 802.3af Power over Ethernet
Injector Hub/POE-1200G :: Detalle de Producto :: The PLANET POE-1200G is 12-Port Gigabit IEEE 802.3af PoE Web Management injector
Hub and complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3af
standards. With 12 10/100/1000Base-T Gigabit Ethernet ports, the
POE-1200G supports full 48V DC power for any remote IEEE 802.3af powered device
(PD) such as Wireless LAN Access Point, IP phone, and IP Camera. Supporting full
PoE power budget of 190 Watts, the POE-1200G provides sufficient 15.4
Watts PoE power to 12 remote PD devices.
The POE-1200G is installed between a regular Ethernet Switch and the powered
devices; it injects power to the PDs without affecting the data transmission
performance. It offers a cost effective and quick solution to upgrade network
system to IEEE 802.3af Power over Ethernet system without replacing the existing
Ethernet Switch. There are 24 RJ-45 STP ports on the front panel of PoE Injector
Hub, of which 12 ports on the lower stack function as "Data input" and
the other 12 ports on the upper stack function as "PoE (Data and Power)
output". The 12 "PoE output" ports are also the power injectors which
transmit DC Voltage to the CAT 3/4/5/5e/6 cable and transfer data and power
simultaneously between the Injectors and Splitters.
To efficiently manage the powered devices, the POE-1200G provides Web management
interface in which administrators can control the functions including port
Enable / Disable, port priority, system configuration, and Username / Password
changing and smart features for powered devices. The PoE injector Hub can
automatically detect the power status of each port and show massages on its Web
management interface. These features also provide users a cost-effective way to
manage the device via Internet whenever they are at work or at home.
The POE-1200G provides the easiest way to power your Ethernet devices such as IP
Camera on the ceiling and the Wireless Access Point installed on the top of the
building. With 12 10/100/1000Base-T Gigabit Ethernet ports, the POE-1200G
supports full 48V DC power for any remote IEEE 802.3af powered device (PD).
To control the power system of your networking devices, the POE-1200G can
directly co-work with PoE IP phones to build VoIP telephony network in the
office. Furthermore, the POE-1200G can be directly connected to any third party
IEEE 802.3af compliant devices installed 100 meters away.
|
Key Features
|
|
|
|
Interface
• 24-Port
10/100/1000Base-T Gigabit RJ-45 STP
- 12-Port “Data
input”
- 12-Port “PoE (Data + Power) output”
• 1 10/100Base-TX
management port with auto MDI / MDI-X feature
PoE
• Complies
with IEEE 802.3af Power over Ethernet Mid-Span PSE
• Up to 12 IEEE 802.3af
devices powered
• Supports PoE power up to 15.4 Watts for each PoE ports
•
Automatically detect powered device (PD)
• Circuit protection prevents power
interference between ports
• Remote power feeding up to 100m
PoE
Management
• Total PoE power budget control
• Per port PoE function
Enable/Disable
• PoE port power feeding priority
• Per PoE port power
limit
• PD classification detection
• PoE Power Schedule
• Over
Temperature Protection
Management
• Web interface for remote
management
• Supports Network Time Protocol
• Firmware upgrade through Web
interface
• PLANET Smart Discovery utility automatically finds PLANET devices
on the network
• SNMP Trap for alarm notification of
events
Hardware
• 19-inch rack mountable; 1U height
• Reset
button for default setting and system reboot
• LED indicators for PoE ready,
PoE activity, FAN Alert and Power Alert
Standard Compliance
•
IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3ab
1000Base-T
• IEEE 802.3af Power over Ethernet
• FCC Part 15 Class A, CE |
| Model |
POE-1200G |
| Hardware
Specification |
| Interface |
"Data" Input Ports: 12x RJ-45 STP
"PoE (Data+Power)" Output Ports: 12x
RJ-45 STP
Management Port: 1 x RJ-45; 10/100Base-TX, auto-negotiation,
auto-MDI / MDIX |
| Data Rate |
10/100/1000Mbps |
| LED |
System: Power x 1 (Green)
FAN Alert x 1(Green)
Management Port x
2: 10/100 (Orange / Green)
Per PoE Port: PoE in Use x 1 (Green) |
| Network Cable |
10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
100Base-TX: 2-Pair
UTP Cat. 3, 4, 5, up to 100m (328ft)
1000Base-T: 2-pair UTP Cat. 5e, 6 up to
100m (328ft)
EIA/TIA- 568 100-ohm STP (100m) |
| Dimension (W x D x H) |
440 x 200 x 44 mm (1U height) |
| Weight |
2.73kg |
| Power Requirement |
100-240V AC, 50/60 Hz |
| Power Consumption |
200 Watts max. |
| Cooling |
Fan x 1 |
| Power over
Ethernet |
| PoE Standard |
IEEE 802.3af Power over Ethernet / Mid-Span PSE |
| PoE Power supply Type |
Mid-Span |
| PoE Power Output |
Per Port DC 48V 15.4 Watts |
| Power Pin Assignment |
4/5(+), 7/8(-) |
| PoE Power Budget |
190 Watts |
| Management |
| Management Interface |
Web, PLANET Smart Discovery Utility |
| PoE Management |
Power Limit by Priority and Total Limit
Per port power Enable /
Disable
Power feeding priority
Current usage and status
Total power
consumption
Per port power Schedule
|
| Management Feature |
System / Management functions setup
Web firmware upgrade
SNMP Trap for
alarm notification of events
|
| Standards
Conformance |
| Standards Compliance |
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE
802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3af Power over
Ethernet
|
| Regulation Compliance |
FCC Part 15 Class A, CE |
| Environmental
Specification |
| Operating |
Temperature: 0 ~ 50 Degree C
Relative Humidity: 5 ~ 95%
(non-condensing)
|
| Storage |
Temperature: -40 ~ 70 Degree C
Relative Humidity: 5 ~ 95%
(non-condensing)
|
|
