Planet Switch 48-Port 10/100Mbps + 4G TP/SFP/WGSW-5240
[WGSW-5240]

Bs.9.682,66-Iva Incl.

Planet Switch 48-Port 10/100Mbps + 4G TP/SFP/WGSW-5240 :: Detalle de Producto :: The PLANET WGSW-5240 is a 48-Port 10/100Mbps fast Ethernet Switch with 4-Port Gigabit TP / SFP Combo interface which boasts a high performance switch architecture that is capable of providing non-blocking switch fabric and wire-speed throughput as high as 17.6Gbps. Its four built-in GbE uplink ports also offer incredible extensibility, flexibility and connectivity to the Core switch or Servers.

Model	WGSW-5240
Hardware Specification
Network Connector	48-Port RJ-45 for 10/100Base-TX 4-Port Gigabit TP/SFP mini-GBIC combo interfaces
RS-232 connector	One RS-232 DB-9 male connector for switch management
Switch architecture	Store and forward switch architecture.
Switch Fabric	Back-plan up to 17.6Gbps
MAC address	8K MAC address table with Auto learning function
Shared Buffer	7Mbit
Power requirement	90~240V AC, 50/60Hz
Operating environment	0~50 degree C, 5%~90%RH
Storage environment	-20~70 degree C, 5%~90%RH
Dimension (W x D x H)	440 x 280 x 44 mm
Switch Specificationce
Spanning Tree	802.1d, 802.1w
Link Aggregation	12 groups, up to 8 ports per group
Priority Queue	802.1p Class of Service (4 Queues)
Port Mirror	RX/TX/Both
Bandwidth Control	Yes, per port per 64kbps, up to 80Mbps
Strom Control	Per 64kbps, up to 80Mbps
IGMP Snooping	v1, v2
MAC Filtering	Yes
VLAN	Port-Based/802.1q, 4K VLAN ID, 256 groups
Port Analysis	Yes
Static Routing Port	Yes
SManagement Function
Management Interface	Console/Web/Telnet/SNMP
SNMP Version	v1, v2c
Support MIB	Support SNMP MIB II (RFC 1213) Bridge MIB (RFC 1493) RMON group 1,2,3,9 Enterprise private MIB
Standards Conformance
Network Standard	IEEE802.3 10Base-T IEEE802.3u 100Base-TX IEEE802.3z Gigabit SX/LX IEE802.3ab Gigabit 1000Base-T IEEE802.3x Flow Control and Back pressure IEEE802.3ad Port trunk with LACP IEEE802.1d Spanning tree protoco lIEEE802.1w Rapid Spanning Tree IEEE802.1p Class of service IEEE802.1Q VLAN Tagging
EMI	FCC Class A, CE
