Motorola Symbol DS7708 Lector DS7708-SR4U2100TCW
Motorola Symbol DS7708 Lector DS7708-SR4U2100TCW
El Motorola Symbol DS7708 es un lector fijo con patron de lectura omnidireccional, con multiples caracteristicas que lo hacen el mejor de su clase. Sin importar como presente el codigo de barras en su punto de venta, este modelo puede leer practicamente cualquier codigo, desde codigos lineales,1D, bidimensionales 2D, impresos y electronicos, tan rapido como el cajero deslice el producto en la ventana de escaneo. Con una durabilidad extraordinaria le ayudara a minimizar costos y proteger el tiempo productivo, maximizndo el ciclo de vida del equipo y retornandole la inversion realizada. El Symbol DS7708 tambien cuenta con opciones sencillas de conectividad mediante un puerto USB para facilitar su instalacion.
Especificaciones
Complimentary Management Tools
PRODUCT SPEC SHEET
Symbol DS7708
Physical charac teris tics
Dimensions Scanner only:
5.63 in. H x 5.86 in. W x 3.81 in. D
14.3 cm H x 14.9 cm W x 9.7 cm D
Scanner with Table Mount Kit:
6.06 in. H x 5.93 in. W x 3.85 in. D
15.4 cm H x 15.1 cm W x 9.8 cm D
Weight 17.6 oz. / 500 g
Voltage and Current Without auxiliary scanner:
Standby: 5 VDC +/-10% @ 125ma avg.
Operating: 5 VDC +/-10% @ 480ma avg.
With auxiliary scanner:
Standby: 12 VDC +/-10% @ 100ma avg.
Operating: 12 VDC +/-10% @ 400ma avg.
Color Midnight Black
Supported Host Interfaces USB, RS-232, Keyboard Wedge, TGCS (IBM)
46XX over RS485
Keyboard Support Supports over 90 international keyboards
Auxiliary Scanner Interface USB
Electronic Article
Surveillance Compatible with Checkpoint EAS deactivation systems
performance charac teris tics
Swipe Speed Up to 100 in./sec. (254 cm/sec.)
Light Source Two deep red LEDs (660nm)
Imager Field of View 48.0° x 36.7° (bar-code reading)
48.0° x 33.7° (image capture)
Image Sensor 1280 x 960 (bar-code reading)
1280 x 880 (image capture)
Minimum Print Contrast 25% minimum reflective difference
Roll / Pitch / Yaw (Skew) 360˚, ±70˚, ±70˚ typical
user environmen t
Operating Temperature 32˚ to 104˚ F / 0˚ to 40˚ C
Storage Temperature -40˚ to 158˚ F / -40˚ to 70˚ C
Humidity 5% to 85% RH, non-condensing
Environmental Sealing IP52
Electrostatic Discharge
(ESD)
ESD per EN61000-4-2; +/- 25 KV Air Direct; +/- 8 KV
Indirect (without auxiliary scanner)
Ambient Light Range From darkness (0 fcd) to 450 fcd artificial light and
10,000 fcd direct sunlight
symb ology decode capability
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean
3 of 5, GS1 DataBar, Base 32 (Italian Pharma), PDF417, Micro PDF417, Composite Codes,
TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin),
Postal Codes
Refer to Product reference Guide for complete list of symbologies.
minimal element resolu tion
Code 39 – 3 mil, UPC – 7.8 mil, PDF417 – 4 mil, Datamatrix – 7.5 mil, QR Code – 7.5 mil
decode ranges (typical )
Code 39 – 5 mil: 0 – 7.2 in. (0 – 18.3 cm)
UPC/EAN – 10 mil (80%): 0 – 10.0 in. (0 – 25.4 cm)
UPC/EAN – 13 mil (100%): 0 – 10.3 in. (0 – 26.1 cm)
PDF417 – 5 mil: 0 – 3.5 in. (0 – 8.9 cm)
Datamatrix – 10 mil: 0 – 5.0 in. (0 – 12.7 cm)
QR Code – 10 mil: 0 – 4.9 in. (0 – 12.4 cm)
warranty
Subject to the terms of Zebra’s hardware warranty statement, the DS7708 is warranted
against defects in workmanship and materials for a period of 3 years from the date of
shipment. Complete Zebra hardware product warranty statement: www.zebra.c
